Description
| Cutting Diameter (mm): | 10 |
|---|---|
| Radius (mm): | 5 |
| End Cut Type: | Ball Nose |
| Number of Flutes: | 2 |
| Coating (Finish): | AlTiN |
| Material: | Carbide |
| Flute Length (mm): | 10 |
| Shank Diameter (mm): | 10 |
| Shank Type: | Straight |
| Material Application: | Steels; Stainless Steels; Cast Irons; Super Alloys; Hardened Materials |
| Helix Angle (°): | 30 |
| Overall Length (mm): | 66 |
| Cutting Hand: | Right |
| Through Coolant: | No |
| Manufacturer Part Number: | 5651199 |
| Brand: | Iscar |
SolidMill Line – 10mm diameter 2 fluted solid carbide ball nose end mill with a 30° helix angle. This millling cutter has a maximum depth of cut up to 10mm with an overall length of 66mm, it also has a 10mm diameter cylindrical shank and comes with a PVD AlTiN coating which is designed to machine steels (P15-P30), stainless steels (M20-M30), cast irons (K20-K30), heat resistant alloys (S10-S25) and hardened steels (H20-H30).
Features & Benefits:
• Iscar SolidMill is classed as the economical range – Hard PVD AlTiN coating for excelent wear resistance, especially on tough workpiece materials – Cylindrical shank designed for colllet, heatshrink chucks and hydraulic tool holders – Flute options of 2 and 4 flute cutters
