Description
Korloy’s XOMT inserts are suitable for use with the King Drill U-Drill system and are used on the inner pocket. These come in a PC5300 grade forThese come in a PC5335 grade for stainless steel machining, which provides excellent performace and stability whilst significantly reducing built-up edge and tool breakages. The inner pocket insert is specially designed to centralise the drill and reduce cutting load up to 50% on first contact with the workpiece. This ensures much higher accuracy compared to other indexable drills, better surface finish and higher reliability.
Features & Benefits
- Central Inserts for Inner Pocket
- PC5335 Grade for Stainless Steel Machining
- Also suitable for drilling Carbon Steel and Mild Steel
- Central Insert Design Provides Low Cutting Resistance & More Accurate Holes
- For Use With Korloy King Drill
- Optimised for Accuracy and Reduced Tool Failure
- Exceptionally Accurate Compared to other U-Drill/Indexable Drills
Specification
| Category | Hole Making | Sub Category | Indexable Drills | Sub Category 2 | King Drill | Radius | 0.8 | Diameter Range (mm) | 43-50.5 | Grade | PC5335 (Stainless Steel) | t | 5 | d1 | 5.5 | Length | 13.9 | Applicable Materials | Steel, Stainless Steel | Performance | 5 | Brand Range | King Drill | Brand | Korloy |
|---|
