Description
K20 Micrograin Carbide Supercut Spade Drill Inserts come in a wide range of metric and imperial sizes from 9.5-35mm and 3/8″-1-3/8″. These TiAlN coated, self centering inserts, provide extremely accurate drilling and are ideal for high alloy steels, stainless steel & aluminium. The supercut spade drill system is the most versatile drilling system in the world and can machine a huge range of diameters with just 9 different sized holders.
Features & Benefits
- K20 Micrograin Carbide Substrate
- Metric Sizes 9.5-35mm
- Imperial Sizes3/8″-1-3/8″
- Fully Ground & Self Centering Inserts
- Ideal for High Alloy Steels, Stainless Steel & Aluminium
- TiAlN Coated
- Extremely Accurate Drilling, Even In Deep Holes
- Wide Range of Inserts Fit Just One Holder
Specification
| Category | Hole Making | Sub Category | Indexable Drills | Sub Category 2 | Spade Drill | Diameter (mm) | 28.58 | Diameter (Inch) | 1-1/8″ | Point Angle | 132° | Substrate | Carbide | Applicable Materials | Steel, Stainless Steel, Cast Iron, Non-Ferrous | Performance | 3 | Coating Description | TiAlN 850 Coating | Substrate Description | K20 Solid Carbide | Self Centring | Yes | Brand Range | Spade Drill | Brand | YG-1 |
|---|
